    800bmp Side Type Hydraulic Breakers For Mini Excavators 20CrMo Hammer Rock Breaker

    Ask Lasest Price
    Brand Name : CTHB
    Model Number : 40B-50
    Certification : CE/ISO
    Price : USD 786 ~ 11349 / Unit
    Payment Terms : L/C, D/P, T/T, Western Union, PayPal, etc.
    Supply Ability : 5500 Units per Year
    Delivery Time : 5-8 Work Days
    • Product Details
    • Company Profile

    800bmp Side Type Hydraulic Breakers For Mini Excavators 20CrMo Hammer Rock Breaker

    Side Type Light Duty Series Hydraulic Rock Breaker for Excavator Weighted from 4-15 tons


    Introduction

    Hydraulic breaker, also known as a hydraulic hammer or rock breaker, etc.

    Its working principle is to use the hydraulic oil provided by the pump station of the excavator or loader to convert the liquid pressure energy into linear mechanical energy.


    Application

    It is widely used in crushed stone, mines, roads, civil engineering, demolition engineering, special engineering (water engineering, tunnel engineering, etc.), and other engineering construction fields.


    Hydraulic breakers have become an important tool for hydraulic excavators, and some people have installed hydraulic breakers on backhoe loaders or wheel loaders for crushing operations.



    Side Type Rock Breaker Specification - Standard Soosan Series

    ItemsUnitCTHB05CTHB10CTHB20CTHB30CTHB40CTHB43CTHB45CTHB50
    Mainbody Weight (incl.Chisel)kg49537189156214282479
    Breaker Total Weight (incl. Outbody)kg657095158263334559761
    Rock Breaker Dimensionmm880*114*280918*176*3601090*215*4351178*230*5001373*295*7721515*295*7351735*390*9101900*390*910
    Hydraulic Oil FlowI/min15-2515-2520-3025-5040-7050-9060-10080-110
    Hydraulic Pressurekg/cm^280-11090-12090-12090-120110-140120-150130-160150-170
    Blow Frequencybmp850-1450800-1400700-1200600-1100500-900400-800400-800350-700
    Chisel Diametermm35404553687585100
    Suitable Excavator Weightton0.8-1.20.8-2.51.2-3.02.5-4.54-76-97-1410-15

    * The Parameter above may change with the technology improvement, will not notice additionally, please understand.
