Skid Steer Type Hydraulic Rock Breaker Supplier
Box Type Breaker Technical Parameter
| YAKAI Skid Steer Type Rock Breaker Parameter Chart |
| Model | Body Weight (incl. chisel tool) (kg) | Total Weight (kg) | Size (L*W*H) (mm) | Working Oil Flow (I/min) | Hydraulic Pressure (kg/cm^2) | Blow Frequency (bmp) | Chisel Diameter (mm) | Carrier Weight (ton) |
Hydraulic Breaker for Light Weight Excavator |
| CTHB30 | 89 | 155 | 1417*350*305 | 25-50 | 90-120 | 600-1100 | 53 | 2.5-4.5 |
| CTHB40 | 156 | 361 | 1660*328*486 | 40-70 | 110-140 | 500-900 | 68 | 4-7 |
| CTHB43 | 214 | 450 | 1712*328*486 | 50-90 | 120-150 | 400-800 | 75 | 6-9 |
|
* The Parameter above may change with the technology improvement,
will not notice additionally, please understand.
Corresponding Excavator Model Chart
| CTHB20 | CTHB30 | CTHB40 | CTHB43 | CTHB50 | CTHB70 | CTHB81 | CTHB121 |
| CAT | 302.5C | 303C CR 303.5C CR | 205 206 | / | 312 120B | E200B E240 320 | E200B E240 320 | 330 |
| KOMATSU | PC05 PC07-2 | PC10 PC12 PC15 PC20 PC27 | PC45 | PC50 PC60 | PC100 PC120 | PC200 PC210 PC220 PC250 | PC200 PC210 PC220 PC250 | PC300 |
| DOOSAN | SOLAR007 SOLAR010 | DH30 DSL602 SOLAR30 SOLAR035 | DH55 DH60 | S70W | DH130 DH150 | DH210 DH220 DH225 Dh258 | DH210 DH220 DH225 Dh258 | DH300 |
| HYUNDAI | ROBEX28 | ROBEX35 | RB55 RB60 | / | RB130 | R200 R210 R215 R225 R245 R260 | R200 R210 R215 R225 R245 R260 | R335 R360 |
| HITACHI | EX8 EX12 EX17 EX18 EC22 | EX25 EX27 EX30 EX33 EX34 | ZX55 ZX60 | ZX70 | ZX120 ZX130 ZX150 | ZX200 ZX210 ZX220 ZX230 ZX240 ZX250 | ZX200 ZX210 ZX220 ZX230 ZX240 ZX250 | ZX300 ZX330 |
| KOBELCO | / | SK035 | SK55 | SK60 | SK100 SK150 | SK200 SK210 SK220 SK230 SK250 | SK200 SK210 SK220 SK230 SK250 SK270 | SK320 SK350 |
| VOLVO | EC20B | EC30 EC25 EC35 | EC65 | / | EC140 | EC180 EC210 | EC180 EC210 | EC290 |
| ATLAS | / | / | / | / | / | 2006 2306 | 2306 2606 | 3306 |
| SUMITOMO | / | / | S40 | S70 | S135 | SH200 SH210 SH240 S280 | SH200 SH210 SH240 S280 | SH330 SH340
|
Excavator Breakers Introduction
A breaker is a multifunction tool for hydraulic excavators, skid
steer loaders, backhoe loaders. The hydraulic oil in the pump
station of the excavator or loader produces pressure, then offer
the hydraulic breakers the impact power to effectively break stones
and rock gaps in the foundation of buildings and soil.
Hydraulic Breaker Application
It is used in conjunction with hydraulic excavators and other
hydraulic carriers, like skid steer loaders, backhoe loaders, and
so on. Hydraulic Hammer can be widely used in metallurgy, mining,
railways, highways, construction and other construction fields or
processes, mining hard objects such as rocks, reinforced concrete,
cement pavement, old buildings, etc. In crushing and demolition
operations, it can also be used for specific operations such as
riveting, rust removal, vibrating, tamping, and piling by changing
the drill rod
