    Excavator Drilling Machine Yakai CTHB Earth Auger Drill Dig Holes For 1.5Ton-35Ton

    Ask Lasest Price
    Brand Name : CTHB
    Certification : CE / ISO
    Price : USD 4600~7200 / Unit
    Payment Terms : L/C, T/T
    Supply Ability : 3000 Units Per Year
    Delivery Time : 10-15 work days
    • Product Details
    • Company Profile

    Excavator Drilling Machine Yakai CTHB Earth Auger Drill Dig Holes For 1.5Ton-35Ton

    Excavator Drilling Machine Yakai CTHB Earth Auger Drill Dig Holes For 1.5Ton-35Ton


    1. What is Earth Auger

    Earth auger is a construction technology suitable for hole-forming operations in building foundation engineering. Widely used in municipal construction, highway bridges, high-rise buildings and other foundation construction projects, with different drilling tools, it is suitable for dry (short helix), or wet (rotary bucket) and rock formation (core drill) hole-forming operations.


    2. Features of Earth Auger:
    (1) Easy to move and highly maneuverable.
    (2) The construction site is environmentally friendly and clean.
    (3) The hole forming speed is fast.
    (4) The verticality of the hole is high.
    (5) Strong geological adaptability.
    (6) The equipment has advanced performance, high degree of automation and low labor intensity.
    (7) Easy to use and easy to maintain.
    (8) The orifice drops mud and produces less sediment.
    (9) Applicable to various pile foundation projects.
    (10) The hole backfill has less influence on the bored pile.


    3.Detailed structure of earth auger


    4. Earth Auger Specification


    Auger Model200030004500600080001000015000200002500050000
    Suitable Carrier Weight1.5-3T2-4T3-5T4-6T6-8T6-10T10-15T15-20T15-25T20T-35T
    Torque(MAX)2000Nm3000Nm4500Nm6000Nm8000Nm9000Nm15000Nm20000Nm25000Nm50000Nm
    Working Pressure60-240Bar70-240Bar70-240Bar80-240Bar80-240Bar80-240Bar80-240Bar80-240Bar80-310Bar80-360Bar
    Flow20-70Lpm25-70Lpm20-80Lpm50-85Lpm50-85Lpm50-125Lpm60-180Lpm75-220Lpm75-280Lpm75-320Lpm
    Output Shaft(mm)OD65,Hex35OD65,Hex51OD65,Hex5175 Square75 Square75 Square75 Square75 Square75 Square110 Square
    Machine Diameter190mm232mm238mm245mm272mm280mm338mm345mm355mm420mm
    Rotating Speed (Max)65r/min60r/min56r/min50r/min48r/min45r/min38r/min35r/min28r/min20r/min
    Machine Weight28kg74kg95kg134kg160kg168kg240kg272kg320kg540kg
    Drilling Diameter(mm)100-400100-600100-700100-700100-900100-1000200-1500200-1500300-1800300-1800

    * For other diameters and lengths, we can customize service, OEM/ODM

    * The Parameter above may change with the technology improvement, will not notice additionally, please understand.


    5. Customize Your Own Earth Auger Based on Your Work Condition


    Q345B Skid Steer Earth Auger PERMOC Skid Steer Auger Attachment 2Q345B Skid Steer Earth Auger PERMOC Skid Steer Auger Attachment 3
