20CrMo Furukawa Series Rock Breaker Yakai CTHB 20-50ton Top Type
Hydraulic Breaker Hammer
1.Specification of Furukawa Series Hydraulic Breaker Hammer
| Furukawa Series Rock Drill Breaker Parameter Chart |
| Model | Body Weight (incl. chisel tool) (kg) | Working Oil Flow (I/min) | Hydraulic Pressure (kg/cm^2) | Blow Frequency (bmp) | Chisel Diameter (mm) | Carrier Weight (ton) |
Furukawa |
| HB20G | 1760 | 125-200 | 160-180 | 350-850 | 135 | 20-27 |
| HB30G | 2200 | 160-190 | 170-190 | 300-800 | 150 | 28-36 |
| HB40G | 2650 | 190-250 | 170-190 | 300-750 | 160 | 37-50 |
* The Parameter above may change with the technology improvement,
will not notice additionally, please understand.
2.The Correct Way to Use The Hydraulic Rock Hammer
a. The chisel should be perpendicular to the striking surface, and
the chisel may be broken by an oblique strike and damage the
cylinder.
b. The engine should be warmed up for ten minutes before the
crushing operation, especially in winter, which will help the
operation go smoothly; before crushing, visually check whether each
oil pipe leaks oil, deal with the oil leakage in time, and check
whether the oil seal of the breaker leaks oil. If the oil leaks,
the oil seal should be replaced in time, otherwise the dust will
enter the piston and wear the piston.
3.Working Shot
4.Spare Parts
5.Other Series Breaker Hammer
We can not only provide the hydraulic breaker hammers but also the
spare parts.
Box type breaker hammer
Side type breaker hammer
Top type breaker hammer
6.Our Certificate
7.One Unit of Hydraulic Breaker Hammer Include:
a.Chisel × 2 pcs
b.Hydraulic oil Hose × 2 pcs
c.General Tool with Tool Box × 1 set
d.Manual Book in English × 1 pc
e.Nitrogen Gas Charging Kit with Hose & Gas Cylinder × 1 set
8.Other Hot Sale Products:
No matter what industry you are in, choose Yakai hydraulic breakers
as your partner for every task. Fits most haulers such as
excavators, backhoes and skid steers, and demolition robots, and it
will get the job done - fast and economical!
